ORDINANCE NO.  8163



AN ORDINANCE OF THE CITY OF LAWRENCE, KANSAS REPEALING ARTICLE 3 OF CHAPTER V OF THE CITY CODE OF LAWRENCE, KANSAS, 2006 EDITION AND AMENDMENTS THERETO, AND ADOPTING THE INTERNATIONAL RESIDENTIAL CODE, 2006 EDITION, AND EXCEPTING, AMENDING AND MODIFYING CERTAIN OF ITS PROVISIONS.



BE IT ORDAINED BY THE GOVERNING BODY OF THE CITY OF LAWRENCE, KANSAS:



Section 1.  Article 3 of Chapter V of the Code of the City of Lawrence, Kansas, 2006 Edition and amendments thereto, is hereby repealed.



Section 2.  Article 3 of Chapter V of the Code of the City of Lawrence, Kansas, 2006 Edition and amendments thereto, is enacted to read as follows, the intent being to replace the current provisions:



Article 3.  Residential Code



5-301          RESIDENTIAL CODE INCORPORATED.

The International Residential Code, 2006 Edition, published by the International Code Council, is hereby adopted by reference as if it were fully set out in this article, except for those portions that are hereinafter deleted, modified or amended.



5-302          SAME.

Not less than one (1) copy of the International Residential Code, 2006 Edition, marked or stamped in the manner provided by K.S.A. 12-3010, with all sections or portions thereof intended to be omitted clearly marked and showing portions that are amended and to which shall be attached a copy of amendments, shall be filed with the City Clerk and shall be open to inspection and available to the public at reasonable business hours.  Official copies of such Code shall be supplied at the cost of the City to the officials and agencies in the manner listed and set forth in K.S.A.12-3010.  Subsequent references to the "International Residential Code" shall mean the International Residential Code, 2006 Edition as adopted herein.



5-303          SEVERABILITY.

If any section, clause, sentence, or phrase of this ordinance is found to be unconstitutional or is otherwise held invalid by any court of competent jurisdiction, it shall not affect the validity of any remaining parts of this ordinance.



5-304          AMENDMENTS MADE TO THE INTERNATIONAL RESIDENTIAL CODE,

The International Residential Code, 2006 Edition is amended or changed as provided below.  The amendment of any section shall not serve to amend or repeal any other discretely numbered provision of the code, whether or not such provision is considered a section or subsection, unless that section or subsection is specifically referenced in the ordinance.



5-304.1       AE100 Appendix E of the International Residential Code is hereby specifically adopted.



5-304.2       AF100 Appendix F of the International Residential Code is hereby specifically adopted.



5-304.3       AG100 Appendix G of the International Residential Code is hereby specifically adopted.



5-304.4       AJ100 of the International Residential Code is hereby specifically adopted.



5-304.5       AM100 Appendix M of the International Residential Code is hereby specifically adopted.



5-305          Chapter 1 of the International Residential Code is hereby deleted.



5-306                    Section R301.2 of the International Residential Code and the indicated subsections are hereby amended to read as follows:



R301.2  Climatic and geographic design criteria.  Buildings shall be constructed in accordance with the provisions of this code as limited by the provisions of this section. Additional criteria shall be established by the local jurisdiction and set forth in Table R301.2(1).



R301.2.1  Wind limitations.  Buildings and portions thereof shall be limited by wind speed, as defined in Table R301.2(1) and construction methods in accordance with this code.  Basic wind speeds shall be determined from Figure R301.2(4).  Where different construction methods and structural materials are used for various portions of a building, the applicable requirements of this section for each portion shall apply.  Where loads for wall coverings, curtain walls, roof coverings, exterior windows, skylights, garage doors and exterior doors are not otherwise specified, the loads listed in Table R301.2(2) adjusted for height and exposure using Table R301.2(3) shall be used to determine design load performance requirements for wall coverings, curtain walls, roof coverings, exterior windows, skylights, garage doors and exterior doors.  Asphalt shingles shall be designed for wind speeds in accordance with Section R905.2.6.



R301.2.1.1  Design criteria.  Construction in regions where the basic Wind speeds from Figure R301.2(4) equal or exceed 100 miles per hour (45m/s) in hurricane-prone regions, or 110 miles per hour (49m/s) elsewhere, shall be designed in accordance with one of the following:



(A)    American Forest and Paper Association (AF&PA) Wood Frame Construction Manual for One- and Two-Family Dwellings (WFCM); or



(B)    Southern Building Code Congress International Standard for Hurricane Resistant Residential Construction (SSTD 10); or



(C)    Minimum Design Loads for Buildings and Other Structures (ASCE-7); or



(D)    American Iron and Steel Institute (AISI), Standard for Cold-Formed Steel Framing—Prescriptive Method for One- and Two-Family Dwellings (COFS/PM) with Supplement to Standard for Cold-Formed Steel Framing—Prescriptive Method For One- and Two-Family Dwellings.



(E)    Concrete construction shall be designed in accordance with the provisions of this Code.



TABLE R301.2(1)



CLIMATIC AND GEOGRAPHIC DESIGN CRITERIA

Ground

Snow

Load

Wind Speed (mph)

Seismic

Design

Category

Subject to Damage From

Winter

Design

Temp.

Ice Barrier

UnderLayment

Required

Flood

Hazards

Air Freezing

Index

Mean

Annual

Temp.

Weathering

Frost line

Depth

Termite

20 lbs

90

A

Severe

30”

Moderate

to Heavy



No

Ordinance

No. 7594

778 F

Days

56.3



For SI:  1 pound per square foot = 0.0479 kPa, 1 mile per hour = 0.447 m/s.



(A)    Weathering may require a higher strength concrete or grade of masonry than necessary to satisfy the structural requirements of this code.  The weathering column shall be filled in with the weathering index (i.e., “negligible,” “moderate” or “severe”) for concrete as determined from the Weathering Probability Map [Figure R301.2(3)].  The grade of masonry units shall be determined from ASTM C 34, C 55, C 62, C 73, C 90, C 129, C 145, C 216 or C 652.



(B)    The frost line depth may require deeper footings than indicated in Figure R403.1(1).  The jurisdiction shall fill in the frost line depth column with the minimum depth of footing below finish grade.



(C)    The jurisdiction shall fill in this part of the table to indicate the need for protection depending on whether there has been a history of local subterranean termite damage.



(D)    The jurisdiction shall fill in this part of the table with the wind speed from the basic wind speed map [Figure R301.2(4)]  Wind exposure category shall be determined on a site-specific basis in accordance with Section R301.2.1.4.



(E)    The outdoor design dry-bulb temperature shall be selected from the columns of 97½-percent values for winter from Appendix D of the International Plumbing Code.  Deviations from the Appendix D temperatures shall be permitted to reflect local climates or local weather experience as determined by the building official.



(F)    The jurisdiction shall fill in this part of the table with the seismic design category determined from Section R301.2.2.1.



(G)   The jurisdiction shall fill in this part of the table with (a) the date of the jurisdiction’s entry into the National Flood Insurance Program (date of adoption of the first code or ordinance for management of flood hazard areas), (b) the date(s) of the currently effective FIRM and FBFM, or other flood hazard map adopted by the community, as may be amended.



(H)    In accordance with Sections R905.2.7.1, R905.4.3.1, R905.5.3.1, R905.6.3.1, R905.7.3.1 and R905.8.3.1, where there has been a history of local damage from the effects of ice damming, the jurisdiction shall fill in this part of the table with “YES”.  Otherwise, the jurisdiction shall fill in this part of the table with “NO”.



(I)       The jurisdiction shall fill in this part of the table with the 100-year return period air freezing index (BF-days) from Figure R403.3(2) or from the 100-year (99%) value on the National Climatic Data Center data table “Air Freezing Index- USA Method (Base 32°Fahrenheit)” at www.ncdc.noaa.gov/fpsf.html.



(J)     The jurisdiction shall fill in this part of the table with the mean annual temperature from the National Climatic Data Center data table “Air Freezing Index-USA Method (Base 32°Fahrenheit)” at www.ncdc.noaa.gov/fpsf.html.





5-307          Section R310.1  of the International Residential Code and the indicated subsections are hereby amended to read as follows:



                  R310.1  Emergency escape and rescue required.

Basements and every sleeping room shall have at least one operable emergency and rescue opening.  Such opening shall open directly into a public street, public alley, yard or court.  Where basements contain one or more sleeping rooms, emergency egress and rescue openings shall be required in each sleeping room, but shall not be required in adjoining areas of the basement.  Where emergency escape and rescue openings are provided they shall have a sill height of not more than 44 inches (1118 mm) above the floor.  Where a door opening having a threshold below the adjacent ground elevation serves as an emergency escape and rescue opening and is provided with a bulkhead enclosure, the bulkhead enclosure shall comply with Section R310.3.  The net clear opening dimensions required by this section shall be obtained by the normal operation of the emergency escape and rescue opening from the inside.  Emergency escape and rescue openings with a finished sill height below the adjacent ground elevation shall be provided with a window well in accordance with Section R310.2.  Emergency escape and rescue openings shall open directly into a public way, or to a yard or court that opens to a public way.



R310.1.1  Minimum opening area.  All emergency escape and rescue openings shall have a minimum  clear opening of 5.7 square feet (0.530 m2).





Exception: Grade floor openings shall have a minimum net clear opening of 5 square feet (0.465 m2).



R310.1.2  Minimum opening height.  The minimum net clear opening height shall be 24 inches (610 mm).



R310.1.3  Minimum opening width.  The minimum net clear opening width shall be 20 inches (508 mm).



R310.1.4  Operational constraints.  Emergency escape and rescue openings shall be operational from the inside of the room without the use of keys, tools or special knowledge.



R310.1.5  Existing Dwelling Units.  Existing dwelling units or dwelling units under construction, prior to the adoption date of this code, will be required to install an operable window or door for emergency escape or rescue complying with this section of the Code when the finished area of the basement is fifty percent or more of the total square footage of the basement area, or when sleeping room(s) are located within the basement.



5-308          Table N1102.1 of the International Residential Code is hereby amended to read as follows:



TABLE N1102.1

INSULATION AND FENESTRATION REQUIREMENTS BY COMPONENT



CLIMATE

ZONE



FENESTRATION

U-FACTOR



SKYLIGHTb

U-FACTOR



GLAZED

FENSTRATION

SHGC



CEILING

R-VALUE



WOOD

FRAMED WALL



MASS

WALL

R-VALUES



FLOOR

 R-VALUE



BASEMENT

WALL

R-VALUE



SLAB

 R-VALUE

   AND DEPTHh

CRAWL

SPACE WALL

 R-VALUE

1

1.2

0.75

0.40

30

13

3

13

0

0

 0

2

0.75

0.75

0.40

30

13

4

13

0

0

0

3

0.65

0.65

0.40e

30

13

5

19

0

0

0

4 except

Marine

0.40

0.60

NR

30

13

5

19

10/13

10, 2 ft

10/13

5 and

Marine 4

0.35

0.60

NR

30

19 or

13+5g

13

30

10/13

10, 2 ft

10/13

6

0.35

0.60

NR

30

19 or

13+5g

15

30

10/13

10, 4 ft

10/13

7 and 8

0.35

0.60

NR

30

21

19

30

10/13

10, 4 ft

10/13



(A)    R-values are minimums.  U-factors and SHGC are maximums. R-19 insulation shall be permitted to be compressed into a 2X cavity



(B)    The fenestration U-factor column excludes skylights.  The solar heat gain coefficient (SHGC) column applies to all glazed fenestration.



(C)    The first R-value applies to continuous insulation, the second to framing cavity insulation; either insulation meets the requirement.



(D)    R-5 shall be added to the required slab edge R-values for heated slabs.



(E)    There are no solar heat gain coefficient (SHGC) requirements in the Marine Zone.



(F)    Or insulation sufficient to fill the framing cavity, R-19 minimum.



(G)   “13+5” means R-13 cavity insulation plus R-5 insulated sheathing.  If structural sheathing covers 25% or less of the exterior, R-5 sheathing is not required where structural sheathing is used.  If structural sheathing covers more than 25% of exterior, structural sheathing shall be supplemented with insulated sheathing of at least R-2.



(H)    Slab edge insulation may be eliminated for slab on grade floors when heating systems efficiency rating is 90% or better.



5-309           Section N1103.2 of the International Residential Code and indicated subsections are hereby amended to read as follows:



N1103.2 Ducts.



N1103.2.1  Insulation.  Supply and return ducts shall be insulated to a minimum of R-8. Ducts in floor trusses shall be insulated to a minimum of R-6.



Exceptions:

(A)    Ducts or portions thereof located completely inside the building thermal envelope.



(B)    Ducts in attic spaces covered more than 50% by blown in insulation may be R-6.



5-310                    Section N1103.6  of the International Residential Code is hereby amended to read as follows:



N1103.6  Equipment sizing.  Heating and cooling equipment shall be sized as specified in Section M1401.3.



5-311                    Section N1103.7 of the International Residential Code is amended to read as follows:



N1103.7  HVAC equipment performance requirements.  Equipment shall meet the minimum efficiency requirements mandated by federal government minimum efficiency standards of Tables 503.2.3(1), 503.2.3(2), 503.2.3(3), 503.2.3(4), 503.2.3(5), 503.2.3(6), 503.2.3(7), 503.2.3(8), 503.2.3(9), 503.2.3(10) and 503.2.3(11) when tested and rated in accordance with the applicable test procedure.  The efficiency shall be verified through certification under an approved certification program or, if no certification program exists, the equipment efficiency ratings shall be supported by data furnished by the manufacturer.  Where multiple rating conditions or performance requirements are provided, the equipment shall satisfy all stated requirements.  Where components, such as indoor or outdoor coils, from different manufacturers are used, calculations and supporting data shall be furnished by the designer that demonstrate that the combined efficiency of the specified components meets the requirements herein.



5-312                    Section M1307.3 of the International Residential Code and the indicated subsections are hereby amended to read as follows:



M1307.3 Elevation of ignition source.  Permanently fixed mechanical equipment and appliances having an ignition source including but not limited to motors, relays or other electrical devices shall be elevated such that the source of ignition bottom of the cabinet is not less than 14 inches above the floor for upflow furnaces and 18 inches (457 mm) above the floor for downflow furnaces in garages.  For the purpose of this section, rooms or spaces that are not part of the living space of a dwelling unit and that communicate with a private garage through openings shall be considered to be part of the garage.



M1307.3.1  Protection from impact.  Appliances located in a garage or carport shall be protected from impact by automobiles.



5-313                    Section M1401.3 of the International Residential Code is hereby amended to read as follows:



M1401.3 Sizing.  Heating and cooling equipment shall be sized based on building loads calculated in accordance with ACCA Manual J or other approved heating and cooling calculation methodologies.  These calculations shall be provided with each new building permit application submitted to the department having jurisdiction and shall include the following:

(A)    The capacity of each piece of heating and cooling equipment,



(B)    A drawing of each duct system including the size and length of each duct trunk, branch and CFM of each duct branch run,



(C)    The calculation shall include but is not limited to window efficiency and sizes, insulation R-value for floor, wall, and ceiling, orientation of the house, house color, roof color,





(D)    Be submitted with every new one and two family dwelling and any addition that will change the heating and cooling load of the dwelling.



Exception:  Duct design shall be submitted prior to rough-in inspection.



5-314                    Section M1601.1  of the International Residential Code and indicated subsections are hereby amended to read as follows:



M1601.1  Duct design.  Duct systems serving heating, cooling and ventilation equipment shall be fabricated in accordance with the provisions of this section and ACCA Manual D or other approved methods.



M1601.1.1  Above-ground duct systems.  Above-ground duct systems shall conform to the following:



(A)    Equipment connected to duct systems shall be designed to limit discharge air temperature to a maximum of 250°F (121°C).



(B)    Factory-made air ducts shall be constructed of Class 0 or Class 1 materials as designated in Table M1601.1.1(1).



(C)    Fibrous duct construction shall conform to the SMACNA Fibrous Glass Duct Construction Standards or NAIMA Fibrous Glass Duct Construction Standards.



(D)    Minimum thickness of metal duct material shall be as listed in Table M1601.1.1(2). Galvanized steel shall conform to ASTM A 653.



(E)    Use of gypsum products to construct return air ducts or return plenums is permitted, provided that the air temperature does not exceed 125°F (52°C) and exposed surfaces are not subject to condensation.



(F)    Duct systems shall be constructed of materials having a flame spread index not greater than 200.



(G)   Stud wall cavities and the spaces between solid floor joists to be used as air plenums shall comply with the following conditions:



(1)     These cavities or spaces shall not be used as a plenum for supply air.



(2)     These cavities or spaces shall not be part of a required fire-resistance-rated assembly.



(3)     Stud wall cavities shall not convey air from more than one floor level.



(4)     Stud wall cavities and joist-space plenums shall be isolated from adjacent concealed spaces by tight-fitting fire blocking in accordance with Section R602.8.



TABLE M1601.1.1(1)

CLASSIFICATION OF FACTORY-MADE AIR DUCTS



DUCT CLASS

MAXIMUM FLAME-SPREAD RATING

0

1

0

25







TABLE M1601.1.1(2)

GAGES OF METAL DUCTS AND PLENUMS USED FOR HEATING OR COOLING



TYPE OF DUCT

SIZE

(inches)

MINIMUM THICKNESS

(inch)

EQUIVALENT GALVANIZED SHEET GAGE

APPOXIMATE ALUMINUM B & S GAGE

Round ducts and enclosed rectangular ducts

14 or less

Over 14

0.013

0.016

30

28

26

24

Exposed rectangular ducts

14 or less

Over 14

0.016

0.019

28

26

24

22



M1601.1.2  Underground duct systems.  Underground duct systems shall be constructed of approved concrete, clay, metal or plastic. The maximum duct temperature for plastic ducts shall not be greater than 150°F (66°C). Metal Ducts shall be protected from corrosion in an approved manner or shall be completely encased in concrete not less than 2 inches (51 mm) thick. Nonmetallic ducts shall be installed in accordance with the manufacturer’s installation instructions. Plastic pipe and fitting materials shall conform to cell classification 12454-B of ASTM D 1248 or ASTM D 1784 and external loading properties of ASTM D 2412. All ducts shall slope to an accessible point for drainage. Where encased in concrete, ducts shall be sealed and secured prior to any concrete being poured. Metallic ducts having an approved protective coating and nonmetallic ducts shall be installed in accordance with the manufacturer’s installation instructions.



5-315                    Section M1701.4 of the International Residential Code is hereby amended to read as follows:



M1701.4  Prohibited sources.  Combustion air ducts and openings shall not connect appliance enclosures with space in which the operation of a fan may adversely affect the flow of combustion air. Combustion air shall not be obtained from an area in which flammable vapors present a hazard. Fuel-fired appliances shall not obtain combustion air from any of the following rooms or spaces:



(A)    Sleeping rooms.



(B)    Bathrooms.



(C)    Toilet rooms.



(D)    Hot tub rooms.



Exception: The following appliances shall be permitted to obtain combustion air from sleeping rooms, bathrooms and toilet rooms:



(1)     Solid fuel-fired appliances provided that the room is not a confined space and the building is not of unusually tight construction.



(2)     Appliances installed in an enclosure in which all combustion air is taken from the outdoors and the enclosure is equipped with a solid weatherstripped door and self-closing device.



5-316                    Section G2406.2 (303.3) of the International Residential Code is hereby amended to read as follows:



G2406.2 (303.3)  Prohibited locations.  Appliances shall not be located in sleeping rooms, bathrooms, toilet rooms, hot tub rooms, storage closets or surgical rooms, or in a space that opens only into such rooms or spaces, except where the installation complies with one of the following:



(A)    The appliance is a direct-vent appliance installed in accordance with the conditions of the listing and the manufacturer’s instructions.



(B)    Vented room heaters, wall furnaces, vented decorative appliances, vented gas fireplaces, vented gas fireplace heaters and decorative appliances for installation in vented solid fuel-burning fireplaces are installed in rooms that meet the required volume criteria of Section G2407.5.





(C)    A single wall-mounted unvented room heater is installed in a bathroom and such unvented room heater is equipped as specified in Section G2445.6 and has an input rating not greater than 6,000 Btu/h (1.76 kW). The bathroom shall meet the required volume criteria of Section G2407.5.





(D)    A single wall-mounted unvented room heater is installed in a bedroom and such unvented room heater is equipped as specified in Section G2445.6 and has an input rating not greater than 10,000 Btu/h (2.93 kW). The bedroom shall meet the required volume criteria of Section G2407.5.





(C)    The appliance is installed in a room or space that opens only into a bedroom or bathroom, and such room or space is used for no other purpose and is provided with a solid weather-stripped door equipped with an approved self-closing device. All combustion air shall be taken directly from the outdoors in accordance with Section G2407.6.



5-317                    G2417.4.1 of the International Residential Code is hereby amended to read as follows:



G2417.4.1  Test pressure.  The test pressure to be used shall be not less than one and one-half times the proposed maximum working pressure, but not less than 3 10 psig (20 kPa gauge), irrespective of design pressure.  Where the test pressure exceeds 125 psig (862 kPa gauge), the test pressure shall not exceed a value that produces a hoop stress in the piping greater than 50 percent of the specified minimum yield strength of the pipe.



5-318                    Section G2445.2  of the International Residential Code is hereby amended to read as follows:



G2445.2  Prohibited use.   One or more Unvented room heaters shall not be used as the sole source of comfort heating in a dwelling unit.



5-319                    Section P2713  of the International Residential Code is hereby amended to read as follows:



P2713.1  Bathtub waste outlets and overflows.  Bathtubs shall have outlets and overflows at least 1½ inches (38 mm) in diameter, and the waste outlet shall be equipped with an approved stopper.



P2713.2  Bathtub enclosures.  Doors within a bathtub enclosure shall conform to ASME A112.19.15.



P2713.3  Bathtub and whirlpool bathtub valves.  The hot water supplied to bathtubs and whirlpool bathtubs shall be limited to a maximum temperature of 120°F (49°C) by a water- temperature-limiting device that conforms to ASSE 1070, except where such protection is otherwise provided by a combination tub/shower valve in accordance with Section P2708.3.



                  P2713.4 Prohibited location. In no case shall tubs be installed head to head.



5-320          Table P2904.4 of the International Residential Code is hereby amended to read as follows:

5-321    Table 2904.5  of the International Residential Code is hereby amended to read as follows:



5-322        Section P3005.2.7 of the International Residential Code is hereby amended to read as follows:



P3005.2.7  Building drain and building sewer junction.  There shall be a cleanout near the junction of the building drain and the building sewer.  The cleanout shall be either inside or outside the building wall and shall be brought up to the finished ground level or to the basement floor level.  An approved two-way cleanout is allowed to be used at this location to serve as a required cleanout for both the building drain and building sewer.  The cleanout at the junction of the building drain and building sewer shall not be required if the cleanout on a 3-inch (76 mm) or larger diameter soil stack is located within a developed length of 10 feet (3048 mm) of the building drain and building sewer junction.



5-323        Section P3005.4.2 of the International Residential Code is hereby amended to read as follows:



P3005.4.2  Building drain and sewer size and slope.  Pipe sizes and slope shall be determined from Table P3005.4.2 on the basis of drainage load in fixture units (d.f.u.) computed from Table P3004.1 however no building sewer shall be less than four (4) inches in diameter.



5-324        Section P3113 of the International Residential Code and indicated subsections are hereby amended to read as follows:



P3113.1  Size of vents.  The minimum required diameter of individual vents, branch vents, circuit vents, vent stacks and stack vents shall be at least one-half the required diameter of the drain served.  The required size of the drain shall be determined in accordance with Chapter 30. Vent pipes shall be not less than 1¼ inches (32 mm) in diameter.  Vents exceeding 40 feet (12 192 mm) in developed length shall be increased by one nominal pipe size for the entire developed length of the vent pipe.



P3113.2  Developed length.  The developed length of individual, branch, and circuit vents shall be measured from the farthest point of vent connection to the drainage system, to the point of connection to the vent stack, stack vent or termination outside of the building.



P3113.3  Branch vents.  Where branch vents are connected to a common branch vent, the common branch vent shall be sized in accordance with this section, based on the size of the common horizontal drainage branch that is or would be required to serve the total drainage fixture unit (dfu) load being vented.



P3113.4  Sump vents.  Sump vent sizes shall be determined in accordance with Sections P3113.4.1 and P3113.4.2.



P3113.4.1  Sewage pumps and sewage ejectors other than pneumatic.  Drainage piping below sewer level shall be vented in a manner similar to that of a gravity system.  Building sump vent sizes for sumps with sewage pumps or sewage ejectors, other than pneumatic, shall be determined in accordance with Table P3113.4.1.



P3113.4.2  Pneumatic sewage ejectors.  The air pressure relief pipe from a pneumatic sewage ejector shall be connected to an independent vent stack terminating as required for vent extensions through the roof.  The relief pipe shall be sized to relieve air pressure inside the ejector to atmospheric pressure, but shall not be less than 1¼ inches (32 mm) in size.



P3113.5  Total Size of Vents.  The drainage piping of each building and each connection to a public sewer or a private sewage disposal system shall be vented by means of one or more vent pipes, the aggregate cross-sectional area of which shall not be less than that of the largest required building sewer, as determined from Table 710.1(1).  Vent pipes from fixtures located upstream from pumps, ejectors, backwater valves, or other devices that in any way obstruct the free flow of air and other gases between the building sewer and the outside atmosphere shall not be used for meeting the cross-sectional area venting requirements of this section.



Exception:  When connected to a common building sewer, the drainage piping of two (2) or more buildings located on the same lot and under one (1) ownership may be vented by means of piping sized in accordance with Table 710.1(1), provided the aggregate cross-sectional area of all vents is not less than that of the largest required common building sewer.





5-325        Section P3114  of the International Residential Code and indicated subsections are hereby amended to read as follows:



P3114.1  General.  Vent systems using air admittance valves shall comply with this section. Individual and branch-type air admittance valves shall conform to ASSE 1051. Stack-type air admittance valves shall conform to ASSE 1050.



P3114.2  Installation.  The valves shall only be installed with prior approval from the Development Services Division Department Having Jurisdiction, in accordance with the requirements of this section and the manufacturer’s installation instructions.  Air admittance valves shall be installed after the DWV testing required by Section P2503.5.1 or P2503.5.2 has been performed.



P3114.3  Where permitted.  The valves shall only be permitted in the alterations of existing buildings with prior approval from the Department Having Jurisdiction.  Individual vents, branch vents, circuit vents and stack vents shall be permitted to terminate with a connection to an air admittance valve.



P3114.4  Location.  Individual and branch air admittance valves shall be located a minimum of 4 inches (102 mm) above the horizontal branch drain or fixture drain being vented. Stack-type Air admittance valves shall be located a minimum of 6 inches (152 mm) above the flood level rim of the highest fixture being vented.  The air admittance valve shall be located within the maximum developed length permitted for the vent.  The air admittance valve shall be installed a minimum of 6 inches (152 mm) above insulation materials where installed in attics.



P3114.5  Access and ventilation.  Access shall be provided to all air admittance valves.  The valve shall be located within a ventilated space that allows air to enter the valve.



P3114.6  Size.  The air admittance valve shall be rated for the size of the vent to which the valve is connected.



P3114.7  Vent required.  Within each plumbing system, a minimum of one stack vent or a vent stack shall extend outdoors to the open air.



P3114.8  Prohibited installations.  Air admittance valves shall not be installed in new construction.



5-326                    Section E3501.6 of the International Residential Code and indicated subsections are hereby amended to read as follows:



E3501.6  Service disconnect required.

Means shall be provided to disconnect all conductors in a building or other structure from the service entrance conductors.



E3501.6.1  Marking of service equipment and disconnects.  Service disconnects shall be permanently marked as a service disconnect.  Service equipment shall be listed for the purpose. Individual meter socket enclosures shall not be considered service equipment.



E3501.6.2  Service disconnect location.  The service disconnecting means shall be installed at a readily accessible location either outside of a building or inside nearest the point of entrance of the service conductors. limited to a distance not to exceed 6 feet from the point of penetration of the service entrance raceway into the structure.  Service disconnecting means shall not be installed in bathrooms.  Each occupant shall have access to the disconnect serving the dwelling unit in which they reside.



5-327                    Section E3504.5 of the International Residential Code is hereby amended to read as follows:



E3504.5  Service masts as supports.  Where a service mast is used for the support of service-drop conductors, it shall be of adequate strength or be supported by braces or guys to withstand the strain imposed by the service drop. a galvanized rigid conduit with a minimum trade size diameter of two inches.  Where the service mast projects above the roof surface in excess of 3 feet the mast shall be supported by braces or guys to withstand safely the strain imposed by the service drop.  Where raceway-type service masts are used, all equipment shall be approved. Only power service drop conductors shall be permitted to be attached to a service mast.



5-328                    Section E3511.2 of the International Residential Code is hereby amended to read as follows:



E3511.2  Accessibility.  The connection of the grounding electrode conductor or bonding jumper to the grounding electrodes that are not buried or concrete encased shall be accessible.



(A)    The location of the grounding electrode connection to the grounding electrode (s) shall be permanently stated on a plaque or directory on the service disconnecting means.



5-329          Section E3602.3 of the International Residential Code is hereby amended to read as follows:



E3602.3 Fifteen- and 20-ampere branch circuits.  A 15- or 20-ampere branch circuit shall be permitted to supply lighting units, or other utilization equipment, or a combination of both. The rating of any one cord-and-plug-connected utilization equipment not fastened in place shall not exceed 80 percent of the branch-circuit ampere rating. The total rating of utilization equipment fastened in place, other than lighting fixtures, shall not exceed 50 percent of the branch-circuit ampere rating where lighting units, cord-and-plug-connected utilization equipment not fastened in place, or both, are also supplied.



(A)    Sump pumps shall be served by an individual branch circuit. The circuit and its receptacle outlet shall be in addition to any other outlets required by E3603.





5-330                    Section E3701.4  of the International Residential Code is hereby amended to read as follows:



E3701.4  Wiring method applications.  Wiring methods shall be applied in accordance with Table E3701.4.



Table E3701.4

ALLOWABLE APPLICATIONS FOR WIRING METHODS a,b,c,d,e,f,g,h,i

ALLOWABLE APPLICATIONS



(applications allowed where marked with an“A”)





AC





EMT





ENT





FMC

IMC

RMC

RNC





LFCa





MC





NM





SR





SE





UF





USE

Services

—

Ah

A

Ai

A

Ai

A

—

—

A—

A

A—

Feeders

A

A

A

A

A

A

A

A

—

Ab

A

Ab

Branch circuits

A

—

A

A

A

A

A

A

A

Ac

A

—

Inside a building

A

A

A

A

A

A

A

A

A

A

A

—

Wet locations exposed to sunlight

—

A

Ah

Ad

A

A

A

—

—

A

Ae

Ae

Damp locations

—

A

A

Ad

A

A

A

—

—

A

A

A

Embedded in non-cinder concrete in dry

Location

—

A

A

—

A

—

—

—

—

—

—

—

In non-cinder concrete in contact with grade

—

Af

A

—

Af

—

—

—

—

—

—

—

Embedded in plaster not exposed to

Dampness

A

A

A

A

A

A

A

—

—

A

A

A

Embedded in masonry

—

A

A

—

Af

A

A

—

—

—

—

—

In masonry voids and cell exposed to dampness or below grade line

—

Af

A

Ad

Af

A

A

—

—

A

A

—

Fished in masonry voids

A

—

—



—







—





—

In masonry voids and cells not exposed to dampness

A

A

A

A

A

A

A

A

A

A

A

A

Run exposed

A

A

A

A

A

A

A

A

A

A

A

A

Run exposed and subject to physical damage

—

—

—

—

Ag

—

—

—

—

—

—

—

For direct burial

—

Af

—

—

Af

A

A

—

—

—



A





For SI:            1 foot = 304.8 mm.



(A)    Liquid-tight flexible nonmetallic conduit without integral reinforcement within the conduit wall shall not exceed 6 feet in length.



(B)    The grounded conductor shall be insulated except where used to supply other buildings on the same premises. Type USE cable shall not be used inside buildings.



(C)    The grounded conductor shall be insulated.



(D)    Conductors shall be a type approved for wet locations and the installation shall prevent water from entering other raceways.



(E)    Shall be listed as “Sunlight Resistant.”



(F)    Metal raceways shall be protected from corrosion and approved for the application.



(G)   RNC shall be Schedule 80.



(H)    Shall be listed as “Sunlight Resistant” where exposed to the direct rays of the sun.



(I)       Conduit shall not exceed 6 feet in length.



5-331                    Section E3801.9  of the International Residential Code is hereby amended to read as follows:



E3801.9  Basements and garages.  At least one receptacle outlet, in addition to any provided for laundry equipment, shall be installed in each basement and in each attached garage, and in each detached garage that is provided with electrical power.  Where a portion of the basement is finished into one or more habitable room(s), each separate unfinished portion shall have a receptacle outlet installed in accordance with this section.



(A)    A receptacle outlet shall be installed in the garage ceiling for each vehicle entry door.  The receptacle outlet shall be located near the center of the finished edges of the opening.  The receptacle outlet shall be located from the opening by the sum total of the height of the door plus a minimum of two feet.



5-332                    Section E3802.12 of the International Residential Code is hereby amended to read as follows:



E3802.12  Arc-fault protection of bedroom outlets.  All branch circuits that supply 120-volt, single-phase, 15- and 20-ampere outlets installed in bedrooms shall be protected by a combination type or branch/feeder type arc-fault circuit interrupter installed to provide protection of the entire branch circuit.  Effective January 1, 2008, such arc-fault circuit interrupter devices shall be combination type.



Exception: The location of the arc-fault circuit interrupter shall be permitted to be at other than the origination of the branch circuit provided that:



(A)    The arc-fault circuit interrupter is installed within 6 feet (1.8 m) of the branch circuit overcurrent device as measured along the branch circuit conductors and



(B)    The circuit conductors between the branch circuit overcurrent device and the arc-fault circuit interrupter are installed in a metal raceway. or a cable with a metallic sheath.



5-333                    Section AF102.1 of the International Residential Code is hereby amended to read as follows:



AF102.1 General.  For the purpose of these requirements, the terms used shall be defined as follows:



SUBSLAB DEPRESSURIZATION SYSTEM (Passive). A system designed to achieve lower sub-slab air pressure relative to indoor air pressure by use of a vent pipe routed through the conditioned space of a building and connecting the sub-slab area with outdoor air, thereby relying on the convective flow of air upward in the vent to draw air from beneath the slab.



SUBSLAB DEPRESSURIZATION SYSTEM (Active). A system designed to achieve lower sub-slab air pressure relative to indoor air pressure by use of a fan-powered vent drawing air from beneath the slab.



ROUGH-IN SUBSLAB DEPRESSURIZATION SYSTEM. A system complying with sections AF103.2, AF103.3, AF103.5, AF103.6, AF103.7, AF103.8, AF103.9.1, AF103.10 and AF103.11.

DRAIN TILE LOOP. A continuous length of drain tile or perforated pipe extending around all or part of the internal or external perimeter of a basement or crawl space footing.



RADON GAS. A naturally-occurring, chemically inert, radio- active gas that is not detectable by human senses. As a gas, it can move readily through particles of soil and rock and can accumulate under the slabs and foundations of homes where it can easily enter into the living space through construction cracks and openings.



SOIL-GAS-RETARDER. A continuous membrane of 6-mil (0.15 mm) polyethylene or other equivalent material used to retard the flow of soil gases into a building.



SUBMEMBRANE DEPRESSURIZATION SYSTEM. A system designed to achieve lower-sub-membrane air pressure relative to crawl space air pressure by use of a vent drawing air from beneath the soil-gas-retarder membrane.



5-334                    Section AF103.1 of the International Residential Code is hereby amended to read as follows:



AF103.1 General.  The following construction techniques are intended to resist radon entry and prepare the building for post-construction radon mitigation, if necessary (see Figure AF102). These techniques are required in areas where designated by the jurisdiction.



Exception: The installation of a rough-in subslab depressurization system as defined in section AF102.1 shall be permitted.



5-335                    Section AF103.9 of the International Residential Code is hereby amended to read as follows:



AF03.9 Vent pipe identification.  All exposed and visible interior radon vent pipes shall be identified with at least one label on each floor and in accessible attics. The label shall read: “Radon Reduction System.”



AF103.9.1  Rough-in Subslab depressurization system pipe identification.  All exposed and visible interior radon vent pipes installed as part of a Rough-in subslab depressurization system as defined in section AF102.1 shall be identified with at least one label on each floor and in accessible attics. The label shall read: “This vent pipe is part of a rough-in for a radon reduction system. This system is not currently operational.  This is not part of the plumbing system.”





Section 3.  This ordinance shall be in full force and take effect on January 1, 2008, and after its publication as provided by law.











Passed by the Governing Body this ____ day of _____________, 2007.







                                                                        Sue Hack, Mayor









ATTEST:









Frank S. Reeb, City Clerk





Approved as to form and legality:









Toni Ramirez Wheeler, Director of Legal Services
